| Micro 60 - M6 holes on 1 inch grid | |  |   | | | Brand: Halcyonics | Details: **This version of the Micro 60 has a special top plate with M6 tapped holes on a 25 mm pitch.
Based on Halcyonics’ proven VarioControl technology, the new benchtop units now offer the convenience of a digital easy-to-navigate menu. VarioControl units offer two digital displays; one for menu navigation and a second to obtain additional information on current vibration levels. Vibration signals of sensors and actuators can be chosen and visualized as graphical bars. The user therefore always obtains summarized information on the current vibration condition of the application. Halcyonics Micro systems feature an automated transport locking mode and fully automatic load adjustment; they take only a few seconds to start up. There is no further adjusting or tuning required. Thus, the Micro systems offer ideal portability even for field measurements and presentations.
Thanks to Halcyonics VarioControl technology, active vibration isolation takes effect right at 0.6 Hz and considerably increases from this frequency upward. Above 10 Hz, Halcyonics Micro systems achieve an isolation of 40 dB – that means that 99.0% of the vibration is effectively isolated. In addition to their high isolation from floor vibration through AVI (active vibration isolation), A major advantage of active Halcyonics systems is that they do not have any natural low-frequency resonance, which is responsible for problems encountered with passive vibration isolation systems in low-frequency ranges below 5 Hz. Micro systems isolate vertical and horizontal vibration as well as vibration generated around the vertical axis of rotation as well as both horizontal axes of inclination. The degree of freedom of the active isolation system is thus six.
- Exceptionally compact dimensions
- Automated auto-levelling and transportation lock
- AC power from an electrical outlet is sufficient; no compressed air supply is needed
- Provides better vibration isolation than is normally possible with complicated, large optical tables
- No natural low-frequency resonance; excellent vibration characteristics also in frequency ranges below 5 Hz
- Active isolation in all six degrees of freedom
- USB 1.1 port and evaluation software for Microsoft Windows PCs
| | Installation: Click here for Data Sheet | | Shipping Cost: $0 | | Shipping Info: Usually ships within 5 days. |
Listing Price: $0 | Selling Price: $0 |
|     |
|
|
Micro 60 - M6 holes on 1 inch grid - Vibration Isolation Benchtop and Vibration Isolation by Halcyonics
Micro 60 - M6 holes on 1 inch grid is a great Vibration Isolation Benchtop and Vibration Isolation by Halcyonics. Enjoy the great selection of Vibration Isolation Benchtop and Vibration Isolation
Bench top vibration isolation systems are a great tool for the lab. Conduct your testing without the fear of vibration interfering with your results. Bench top vibration isolation systems use active control to give you far superior results when conducting your testing. Benchtop isolation can be done with any one of our high end benchtop vibration isolation system. If vibration isolation is important for you, this is the solution you need.
There are many passive solutions available that try and accomplish a similar task, however, they cannot compete with the power and versatility of an active control system. Any kind of laboratory work that requires precision can only be done correctly with a bench top vibration isolation system. Active Benchtop vibration isolation systems respond to environmental conditions, cancelling out contaminating energy before it can reach your testing setup. This can be important for all kind of industries ranging from electronics to biologists and fabrication systems.
|
|
